  • Multi-stage Transformer Oil Filter Machine, Dielectric Oil Filtration System, Transformer Oil Purification System

    Multi-stage Transformer Oil Filter Machine, Dielectric Oil Filtration System, Transformer Oil Purification System

    Multi-stage Transformer Oil Filter Machine, Dielectric Oil Filtration System, Transformer Oil Purification System

  • Detailed description
  • Under normal circumstances, the single stage Vacuum Oil filter plant is extremely effective. However in exceptional cases where a higher state of vacuum is required to maintain low value of dissolved gases and moisture, we offer a double or three stage vacuum oil filter machine to solve this matter.



    Added advantage of this system include the facility of improving quality of filtered oil to a higher level under single pass at a temperature of about 60 degree.



    Special Features:   In addition to the above, the following special features can be incorporated in the oil filtration plant



    (a) Alarm Annunciators

    (b) Moisture Content meter

    (c) Gas content meter



    (d).  Digital Electronic measuring Instruments

    (e).  Oil Flow meter

    (f).  Transformer evacuation system

    (g).  It can purify transformer oil on-line without cutting off the power

    (h).  Duplex 3D stereo-evaporation, eliminating the liquid water quickly

    (i).   UK G technology by which the trace water that is show chain, such as dissolved water, can be removed effectively.



    (j).  Distinctive removing impurities system filtering through double FH trapezoidal network and absorbing by high polymer without the mechanical power

    (k).   Carbon fiber infrared heating system that can make the oil contains zero sum of ethyne after the treatment

    (l).    Especially applied to vacuum oiling and drying for power transmission equipments which are over 110KV

    (m).  Can be operated both on-load and off-load.

    (n).   Can be operated fully-automatically with PLC controller.

    (o).   This Oil Filter Machine can be made in mobile, hermetical, canopy-covering, open and frame styles.



    Ionic Reaction Coloumn:    In certain cases where there is need for decrease in acid content of transforer oil, an ionic reaction coloumn is provided complete with first file up of high grade neutralizing chemicals, an SS wire mesh for supporting media.



    Technical Parameters:   We achieve the following value of filteration





    Before Filteration

    After Filteration

    Single Stage

    After Filteration

    Two / Three Stage





    Dielectric Strength





    20 KV





    60 KV





    75-80 KV





    Moisture content





    88 ppm





    6 ppm





    2 ppm





    Suspended impurities





    more than 100 micron





    5 micron





    1 micron







    Gas content







    10%







    0.1%







    0.01%





    Source:  oil purifier, oil purification, oil filtration system, oil restoration, oil re-processing, oil recycling
